Excavator Bucket Reconstruction
Western Australia·2024
01
Challenge
An excavator bucket required reconstruction, needing reverse engineering to produce accurate manufacturing data where original drawings were unavailable.
02
Approach
We laser scanned the excavator bucket and reverse engineered the component to produce reconstruction documentation.
03
Engineering Process
- 13D laser scan of the excavator bucket
- 2Reverse engineering from point cloud data
- 33D model reconstruction
- 4Manufacturing documentation
04
Deliverables
- Reverse-engineered 3D model
- Manufacturing documentation
05
Outcome
The excavator bucket was reverse engineered and documented, enabling reconstruction without original drawings.
